Engine features:
Engine cylinder block made from high-strength alloy cast has better rigidity, reduced vibration and noise;Four-valve per cylinder optimizes the air/fuel mixture;Some engines adopt Cummins-patented PT fuel system with unique overspeed protection;Some models are equipped with electronic control device, increasing the power and emission targets of
engines and providing guidance on engine maintenance.
| 50HZ （DCEC） | ||||||||||
| Genset Model | Standby Power | Prime Power | Engine Model | Alternator Model | Fuel Consumption | Genset Weight kg | Genset type Dimension (mm) | Click for Detail Data | ||
| (kW/kVa) | (kW/kVa) | Cummins | Stamford | L/H | Open type | Silent type | Open type | Silent type | ||
| SQC27 | 22/27 | 20/25 | 4B3.9-G2 | PI144E | 6.3 | 777 | 1380 | 1580×650×1146 | 2350×1133×1516 |  |
| SQC30 | 24/30 | 22/27.5 | 4B3.9-G1 | PI144F | 6.5 | 777 | 1380 | 1580×650×1146 | 2350×1133×1516 | |
| SQC30 | 24/30 | 22/27.5 | 4B3.9-G2 | PI144F | 6.5 | 777 | 1380 | 1580×650×1146 | 2350×1133×1516 | |
| SQC33 | 26.4/33 | 24/30 | 4BT3.9-G1 | PI144G | 6.7 | 830 | 1420 | 1800×730×1290 | 2350×1133×1516 | |
| SQC33 | 26.4/33 | 24/30 | 4BT3.9-G2 | PI144G | 6.7 | 830 | 1420 | 1800×730×1290 | 2350×1133×1516 | |
| SQC40 | 31/39 | 28/35 | 4BT3.9-G1 | PI144H | 8.3 | 830 | 1420 | 1800×730×1290 | 2350×1133×1516 | |
| SQC40 | 31/39 | 28/35 | 4BT3.9-G2 | PI144H | 8.3 | 830 | 1420 | 1800×730×1290 | 2350×1133×1516 | |
| SQC45 | 35/44 | 32/40 | 4BT3.9-G1 | PI144J | 9.4 | 830 | 1420 | 1800×730×1290 | 2350×1133×1516 | |
| SQC45 | 35/44 | 32/40 | 4BT3.9-G2 | PI144J | 9.4 | 830 | 1420 | 1800×730×1290 | 2350×1133×1516 | |
| SQC55 | 44/55 | 40/50 | 4BTA3.9-G2 | UCI224D | 11.7 | 926 | 1530 | 1900×783×1257 | 2350×1133×1516 | |
| SQC65 | 53/66 | 48/60 | 4BTA3.9-G2 | UCI224E | 13.8 | 975 | 1540 | 1900×783×1257 | 2350×1133×1516 | |
| SQC80 | 64/80 | 58/72 | 4BTA3.9-G11 | UCI224F | 16.2 | 975 | 1540 | 1900×783×1257 | 2350×1133×1516 | |
| SQC95 | 74/93 | 68/85 | 6BT5.9-G1 | UCI224G | 19.5 | 1249 | 2037 | 2200×830×1278 | 3200×1133×1766 | |
| SQC95 | 74/93 | 68/85 | 6BT5.9-G2 | UCI224G | 19.5 | 1249 | 2037 | 2200×830×1278 | 3200×1133×1766 | |
| SQC110 | 88/110 | 80/100 | 6BT5.9-G1 | UCI274C | 22.9 | 1272 | 2059 | 2200×830×1278 | 3200×1133×1766 | |
| SQC110 | 88/110 | 80/100 | 6BT5.9-G2 | UCI274C | 22.9 | 1272 | 2059 | 2200×830×1278 | 3200×1133×1766 | |
| SQC125 | 100/125 | 91/114 | 6BTA5.9-G2 | UCI274D | 25.5 | 1297 | 2130 | 2200×830×1325 | 3200×1133×1766 | |
| SQC138 | 110/138 | 100/125 | 6BTAA5.9-G2 | UCI274ES | 29.5 | 1381 | 2168 | 2360×830×1334 | 3200×1133×1766 | |
| SQC150 | 120/150 | 110/138 | 6BTAA5.9-G2 | UCI274E | 29.5 | 1381 | 2168 | 2360×830×1334 | 3200×1133×1766 | |
| SQC165 | 132/165 | 120/150 | 6BTAA5.9-G12 | UCI274F | 34.8 | 1420 | 2430 | 2360×830×1334 | 3200×1133×1766 | |
| SQC175 | 140/175 | 128/160 | 6CTA8.3-G1 | UCI274F | 35.7 | 1782 | 3040 | 2360×847×1366 | 3600×1333×2040 | |
| SQC175 | 140/175 | 128/160 | 6CTA8.3-G2 | UCI274F | 35.7 | 1782 | 3040 | 2360×847×1366 | 3600×1333×2040 | |
| SQC200 | 160/200 | 145/182 | 6CTA8.3-G1 | UCI274G | 41.2 | 1832 | 3100 | 2360×847×1366 | 3600×1333×2040 | |
| SQC200 | 160/200 | 145/182 | 6CTA8.3-G2 | UCI274G | 41.2 | 1832 | 3100 | 2360×847×1366 | 3600×1333×2040 | |
| SQC220 | 176/220 | 160/200 | 6CTAA8.3-G2 | UCI274H | 43.3 | 1850 | 3040 | 2400×980×1460 | 3600×1333×2040 | |
| SQC250 | 200/250 | 180/225 | 6LTAA8.9-G2 | UCDI274J | 47.8 | 1960 | 3380 | 2540×1018×1527 | 3600×1333×2040 | |
| SQC275 | 220/275 | 200/250 | 6LTAA8.9-G2 | UCDI274K | 53 | 1985 | 3400 | 2540×1018×1527 | 3600×1333×2040 | |
| SQC288 | 230/288 | 210/263 | 6LTAA8.9-G3 | HCI444D | 54 | 2204 | 3619 | 2540×1018×1527 | 3600×1333×2040 | |
| SQC415 | 330/413 | 300/375 | 6ZTAA13-G3 | HCI444F | 73.5 | 3600 | 6400 | 3250×1360×2100 | 5000×1983×2371 | |
| SQC460 | 368/460 | 350/438 | 6ZTAA13-G2 | HCI544C | 87 | 3700 | 6450 | 3250×1360×2100 | 5000×1983×2371 | |
| SQC460 | 368/460 | 360/450 | 6ZTAA13-G4 | HCI544C | 89.5 | 3700 | 6450 | 3250×1360×2100 | 5000×1983×2371 | |
| SQC500 | 400/500 | 360/450 | QSZ13-G2 | HCI544C | 98 | 3700 | 6450 | 3250×1360×2100 | 5000×1983×2371 | |
| SQC550 | 440/550 | 400/500 | QSZ13-G3 | HCI544D | 101 | 3700 | 6450 | 3250×1360×2100 | 5000×1983×2371 | |
| 50HZ (CCEC) | ||||||||||
| Genset Model | Standby Power | Prime Power | Engine Model | Alternator Model | Fuel Consumption | Genset Weight Kg | Genset overall LxWxH (mm) | click for datail data | ||
| kW/kVa | kW/kVa | Cummins | Stamford | L/H | Open type | Silent type | Open Type | Silent type | ||
| SQC250 | 200/250 | 180/225 | NT855-GA | UCDI274J | 47.5 | 2460 | 4200 | 3000×1054×1758 | 4300×1483×2145 | |
| SQC275 | 220/275 | 200/250 | NT855-GA | UCDI274K | 52.3 | 2490 | 4250 | 3000×1054×1758 | 4300×1483×2145 | |
| SQC275 | 220/275 | 200/250 | MTA11-G2 | UCDI274K | 53.2 | 2370 | 4123 | 2750×1050×1585 | 4300×1483×2145 | |
| SQC315 | 250/315 | 220/275 | NTA855-G1A | HCI444D | 61 | 2810 | 4450 | 3000×1054×1758 | 4300×1483×2145 | |
| SQC350 | 280/350 | 256/320 | NTA855-G1B | HCI444ES | 68.3 | 2920 | 4495 | 3000×1054×1758 | 4300×1483×2145 | |
| SQC350 | 280/350 | 256/320 | MTAA11-G3 | HCI444ES | 63 | 2300 | 4887 | 3000×1140×1600 | 4500×1583×2100 | |
| SQC385 | 308/385 | 280/350 | NTA855-G2A | HCI444E | 72 | 3120 | 4495 | 3000×1054×1758 | 4300×1483×2145 | |
| SQC390 | 312/390 | 283/354 | NTA855-G4 | HCI444E | 75 | 3280 | 4495 | 3000×1054×1758 | 4300×1483×2145 | |
| SQC415 | 330/413 | 300/375 | NTAA855-G7 | HCI444FS | 83.5 | 2864 | 5327 | 3250×1120×1721 | 4500×1583×2100 | |
| SQC438 | 350/438 | 320/400 | QSNT-G3 | HCI444F | 85 | 2875 | 5350 | 3250×1120×1721 | 4500×1583×2100 | |
| SQC450 | 360/450 | 320/400 | NTAA855-G7A | HCI444F | 87 | 2880 | 5360 | 3250×1120×1721 | 4500×1583×2100 | |
| SQC500 | 400/500 | 360/450 | KTA19-G3 | HCI544C | 95.1 | 3800 | 6500 | 3350×1280×1934 | 4800×1683×2200 | |
| SQC550 | 440/550 | 400/500 | KTA19-G3A | HCI544D | 94.6 | 3940 | 6630 | 3350×1280×1934 | 4800×1683×2200 | |
| SQC550 | 440/550 | 400/500 | KTA19-G4 | HCI544D | 97 | 3940 | 6630 | 3350×1280×1934 | 4800×1683×2200 | |
| SQC600 | 480/600 | 440/550 | KTAA19-G5 | HCI544E | 113 | 4020 | 6650 | 3525×1550×2032 | 5000×1983×2371 | |
| SQC660 | 528/660 | 480/600 | KTA19-G8 | HCI544E | 126 | 4150 | 6800 | 3350×1280×1934 | 4800×1683×2200 | |
| SQC688 | 550/688 | 500/625 | KTAA19-G6A | HCI544FS | 128 | 4220 | 6700 | 3525×1550×2032 | 5000×1983×2371 | |
| SQC700 | 560/700 | 504/630 | KT38-G | HCI544F | 140 | 4220 | 6700 | 3525×1550×2032 | 5000×1983×2371 | |
| SQC715 | 572/715 | 520/650 | QSKTAA19-G4 NR2 | HCI544F | 145 | 6600 | 9000 | 3525×1550×2032 | 5000×1983×2371 | |
| SQC800 | 640/800 | 582/728 | KT38-GA/G1 | LVI634B | 225 | 6785 | 11985 | 4200×1805×2383 | 6058×2438×2896 | |
| SQC825 | 660/825 | 600/750 | KTA38-G2 | LVI634B | 167 | 7000 | 12200 | 4200×1805×2383 | 6058×2438×2896 | |
| SQC880 | 704/880 | 640/800 | KTA38-G2B | HCI634G | 169 | 7140 | 12350 | 4200×1805×2383 | 6058×2438×2896 | |
| SQC1000 | 800/1000 | 728/910 | KTA38-G2A | HCI634H | 196 | 7140 | 12450 | 4200×1805×2383 | 6058×2438×2896 | |
| SQC1100 | 880/1100 | 800/1000 | KTA38-G5 | HCI634J | 209 | 7310 | 12510 | 4200×1805×2244 | 6058×2438×2896 | |
| SQC1250 | 1000/1250 | 900/1125 | KTA38-G9 | HCI634K | 210 | 8100 | 13417 | 4350×2090×2178 | 6058×2438×2896 | |
| SQC1375 | 1100/1375 | 1000/1250 | QSK38-G5 | PI734A | 274 | 7800 | 15800 | 5140×1850×2340 | 12192×2438×2896 | |
| SQC1375 | 1100/1375 | 1000/1250 | KTA50-G3 | PI734A | 254 | 9038 | 16850 | 5000×1850×2343 | 12192×2438×2896 | |
| SQC1540 | 1232/1540 | 1120/1400 | KTA50-G8 | PI734C | 289 | 9522 | 18322 | 5200×2260×2510 | 12192×2438×2896 | |
| SQC1650 | 1320/1650 | 1200/1500 | KTA50-GS8 | PI734C | 309 | 9900 | 18500 | 5200×2260×2510 | 12192×2438×2896 | |
| 60HZ (DCEC) | ||||||||||
| Genset Model | Standby Power | Prime Power | Engine Model | Alternator Model | Fuel Consumption L/H (full load100%) | Genset Weight Kg | Genset overall LXWXH (mm) | click for datail data | ||
| kW/kVa | kW/kVa | Open type | Silent type | Open Type | Silent type | |||||
| SQC25-6 | 19/24 | 17.5/21.9 | 4B3.9-G1 | PI044H | 6.3 | 750 | 1390 | 1580×650×1146 | 2350×1133×1516 | |
| SQC25-6 | 19/24 | 17.5/21.9 | 4B3.9-G2 | PI044H | 6.3 | 750 | 1390 | 1580×650×1146 | 2350×1133×1516 | |
| SQC33-6 | 26.5/33 | 24/30 | 4B3.9-G1 | PI144E | 8.6 | 777 | 1390 | 1580×650×1146 | 2350×1133×1516 | |
| SQC33-6 | 26.5/33 | 24/30 | 4B3.9-G2 | PI144E | 8.6 | 777 | 1390 | 1580×650×1146 | 2350×1133×1516 | |
| SQC40-6 | 33/41 | 30/37.5 | 4BT3.9-G1 | PI144G | 9.5 | 802 | 1420 | 1800×730×1290 | 2350×1133×1516 | |
| SQC40-6 | 33/41 | 30/37.5 | 4BT3.9-G2 | PI144G | 9.5 | 802 | 1420 | 1800×730×1290 | 2350×1133×1516 | |
| SQC45-6 | 36/45 | 34/42 | 4BT3.9-G2 | PI144H | 10.7 | 802 | 1420 | 1800×730×1290 | 2350×1133×1516 | |
| SQC60-6 | 48/60 | 44/55 | 4BTA3.9-G2 | UCI224C | 13.8 | 926 | 1540 | 1900×783×1257 | 2350×1133×1516 | |
| SQC70-6 | 56/70 | 50/62 | 4BTA3.9-G2 | UCI224D | 15.9 | 926 | 1540 | 1900×783×1257 | 2350×1133×1516 | |
| SQC85-6 | 66/83 | 60/75 | 4BTA3.9-G2 | UCI224E | 17.8 | 926 | 1540 | 1900×783×1257 | 2350×1133×1516 | |
| SQC100-6 | 80/100 | 72/90 | 4BTA3.9-G11 | UCI224F | 20.5 | 926 | 1540 | 1900×783×1257 | 2350×1133×1516 | |
| SQC110-6 | 88/110 | 80/100 | 6BT5.9-G2 | UCI224G | 25.6 | 1220 | 2059 | 2200×830×1278 | 3200×1133×1766 | |
| SQC125-6 | 100/125 | 91/114 | 6BT5.9-G1 | UCI274C | 29 | 1272 | 2059 | 2200×830×1278 | 3200×1133×1766 | |
| SQC125-6 | 100/125 | 91/114 | 6BT5.9-G2 | UCI274C | 29 | 1272 | 2059 | 2200×830×1278 | 3200×1133×1766 | |
| SQC145-6 | 116/145 | 105/131 | 6BTA5.9-G2 | UCI274D | 31 | 1290 | 2090 | 2200×830×1325 | 3200×1133×1766 | |
| SQC165-6 | 132/165 | 120/150 | 6BTAA5.9-G2 | UCI274E | 34.3 | 1370 | 2178 | 2360×830×1334 | 3200×1133×1766 | |
| SQC180-6 | 143/180 | 130/163 | 6BTAA5.9-G12 | UCI274E | 37.8 | 1420 | 2430 | 2360×830×1334 | 3200×1133×1766 | |
| SQC195-6 | 157/195 | 143/178 | 6CTA8.3-G1 | UCI274E | 41.4 | 1755 | 3050 | 2360×847×1366 | 3600×1333×2040 | |
| SQC195-6 | 157/195 | 143/178 | 6CTA8.3-G2 | UCI274E | 41.4 | 1755 | 3050 | 2360×847×1366 | 3600×1333×2040 | |
| SQC220-6 | 176/220 | 160/200 | 6CTA8.3-G1 | UCI274F | 44.7 | 1755 | 3050 | 2360×847×1366 | 3600×1333×2040 | |
| SQC220-6 | 176/220 | 160/200 | 6CTA8.3-G2 | UCI274F | 44.7 | 1755 | 3050 | 2360×847×1366 | 3600×1333×2040 | |
| SQC240-6 | 192/240 | 175/220 | 6CTAA8.3-G2 | UCI274G | 49 | 1800 | 3204 | 2400×980×1460 | 3600×1333×2040 | |
| SQC275-6 | 220/275 | 200/250 | 6LTAA8.9-G2 | UCI274H | 54.4 | 1940 | 3050 | 2540×1018×1527 | 3600×1333×2040 | |
| SQC300-6 | 240/300 | 218/273 | 6LTAA8.9-G2 | UCDI274J | 60 | 1940 | 3390 | 2540×1018×1527 | 3600×1333×2040 | |
| SQC325-6 | 260/325 | 236/295 | 6LTAA8.9-G3 | UCDI274J | 62 | 1940 | 3400 | 2540×1018×1527 | 3600×1333×2040 | |
| SQC415-6 | 330/413 | 300/375 | 6ZTAA13-G3 | HCI444D | 77.8 | 3600 | 6400 | 3250×1360×2100 | 5000×1983×2371 | |
| SQC460-6 | 368/460 | 360/450 | 6ZTAA13-G2 | HCI444FS | 81 | 3600 | 6400 | 3250×1360×2100 | 5000×1983×2371 | |
| SQC460-6 | 368/460 | 360/450 | 6ZTAA13-G4 | HCI444FS | 81 | 3600 | 6400 | 3250×1360×2100 | 5000×1983×2371 | |
| 60HZ (CCEC) | ||||||||||
| Genset Model | Standby Power | Prime Power | Engine Model | Alternator Model | Fuel Consumption L/H (full load100%) | Genset Weight Kg | Genset overall LXWXH (mm) | click for detail data | ||
| kW/kVa | kW/kVa | Open type | Silent type | Open Type | Silent type | |||||
| SQC275-6 | 220/275 | 200/250 | NT855-GA | UCI274H | 60.4 | 2485 | 4120 | 3000×1054×1758 | 4300×1483×2145 | |
| SQC350-6 | 280/350 | 256/320 | NTA855-G1 | HCI444D | 70.1 | 2840 | 4470 | 3000×1054×1758 | 4300×1483×2145 | |
| SQC375-6 | 300/375 | 275/344 | NTA855-G1B | HCI444D | 70.5 | 2869 | 4470 | 3000×1054×1758 | 4300×1483×2145 | |
| SQC440-6 | 352/440 | 320/400 | NTA855-G3 | HCI444E | 85.1 | 2940 | 4515 | 3000×1054×1758 | 4300×1483×2145 | |
| SQC500-6 | 400/500 | 360/450 | KTA19-G2 | HCI444FS | 95.8 | 3627 | 6440 | 3350×1280×1934 | 4800×1683×2200 | |
| SQC550-6 | 440/550 | 400/500 | KTA19-G3 | HCI444F | 101 | 3830 | 6490 | 3350×1280×1934 | 4800×1683×2200 | |
| SQC565-6 | 450/565 | 410/513 | KTA19-G3 | HCI544C | 103.5 | 3850 | 6520 | 3350×1280×1934 | 4800×1683×2200 | |
| SQC625-6 | 500/625 | 450/565 | KTA19-G3A | HCI544C | 117 | 3870 | 6600 | 3350×1280×1934 | 4800×1683×2200 | |
| SQC625-6 | 500/625 | 450/565 | KTA19-G4 | HCI544C | 117 | 3870 | 6600 | 3350×1280×1934 | 4800×1683×2200 | |
| SQC688-6 | 550/688 | 470/588 | KTAA19-G5 | HCI544D | 134 | 3950 | 6720 | 3525×1550×2032 | 5000×1983×2371 | |
| SQC750-6 | 600/750 | 546/682 | KTAA19-G6A | HCI544E | 142 | 4100 | 6800 | 3525×1550×2032 | 5000×1983×2371 | |
| SQC750-6 | 600/750 | 546/682 | QSK19-G5 | HCI544E | 151 | 4100 | 6800 | 3525×1550×2032 | 5000×1983×2371 | |
| SQC850-6 | 680/850 | 620/775 | KT38-G | HCI544F | 154 | 6500 | 11667 | 4200×1805×2383 | 6058×2438×2896 | |
| SQC963-6 | 770/963 | 700/875 | KTA38-G1 | HCI634G | 186 | 6750 | 11889 | 4200×1805×2383 | 6058×2438×2896 | |
| SQC1000-6 | 800/1000 | 725/906 | KTA38-G2 | HCI634G | 204 | 6950 | 11947 | 4200×1805×2383 | 6058×2438×2896 | |
| SQC1100-6 | 880/1100 | 800/1000 | KTA38-G2A | HCI634G | 210 | 7150 | 12834 | 4200×1805×2383 | 6058×2438×2896 | |
| SQC1250-6 | 1000/1250 | 900/1125 | KTA38-G4 | HCI634H | 229.5 | 7280 | 13170 | 4200×1805×2244 | 6058×2438×2896 | |
| SQC1375-6 | / | 1100/1375 | KTA38-G9 | HCI634J | 210 | 8100 | 13417 | 4350×2090×2178 | 6058×2438×2896 | |
| SQC1540-6 | 1232/1540 | 1120/1400 | KTA50-G3 | HCI634K | 281.5 | 9150 | 17020 | 5000×1850×2343 | 12192×2438×2896 | |
| SQC1730-6 | 1384/1730 | 1260/1575 | KTA50-G9 | PI734B | 327 | 9560 | 17550 | 5200×2260×2510 | 12192×2438×2896 | |
| SQC1875-6 | 1500/1875 | 1260/1575 | KTA50-G9 | PI734C | 327 | 9590 | 18200 | 5200×2260×2510 | 12192×2438×2896 | |
