SQWD series is characterized by low price, excellentworkmanship, high reliability, strong power, easy to purchase parts and long use time etc.
| Genset Model | Standby Power | Prime Power | Electric current | Diesel Model | Engine Model | Cyli-nders | Exhaust | Fuel Consumption | Genset Weight | Genset overrall L×W×H |
| KW/KVA | KW/KVA | A | L | g/kw.h | kg | mm | ||||
| SQWD138 | 125/138 | 100/110 | 180 | WD129D11 | LTG-100 | 6 | 12.9 | 213 | 1800 | 2650×900×1400 |
| SQWD165 | 150/165 | 120/132 | 216 | WD150D15 | LTG-120 | 6 | 12.9 | 213 | 1800 | 2650×900×1400 |
| SQWD200 | 160/200 | 150/165 | 270 | WD129TD16 | LTG-150 | 6 | 12.9 | 213 | 1900 | 2700×900×1400 |
| SQWD250 | 225/250 | 180/200 | 324 | WD129TD17 | LTG-180 | 6 | 12.9 | 213 | 2100 | 2750×900×1400 |
| SQWD275 | 250/275 | 200/220 | 360 | WD129TAD23 | LTG-200 | 6 | 12.9 | 217 | 2200 | 3000×1100×1750 |
| SQWD315 | 275/315 | 220/250 | 396 | WD129TAD25 | LTG-220 | 6 | 25.8 | 217 | 2250 | 3000×1100×1750 |
| SQWD350 | 320/350 | 250/280 | 450 | WD135TAD28 | LTG-250 | 6 | 25.8 | 221 | 3400 | 3200×1400×1800 |
| SQWD388 | 350/388 | 280/300 | 540 | WD145TAD30 | LTG-280 | 6 | 26.8 | 217 | 3500 | 3000×1400×1800 |
| SQWD415 | 375/415 | 300/330 | 504 | WD145TAD33L | LTG-300 | 6 | 26.8 | 198 | 3600 | 3500×1600×1900 |
| SQWD440 | 400/440 | 320/350 | 576 | WD269TD35 | LTG-320 | 12 | 26.8 | 198 | 3800 | 3500×1600×1900 |
| SQWD475 | 425/475 | 340/380 | 612 | WD269TD38 | LTG-360 | 12 | 26.9 | 198 | 3850 | 3600×1600×1900 |
| SQWD525 | 475/525 | 380/420 | 684 | WD269TAD41 | LTG-400 | 12 | 26.9 | 198 | 4000 | 3650×1700×2000 |
| SQWD540 | 488/540 | 390/430 | 702 | WD269TAD43 | LTG-400 | 12 | 26.9 | 198 | 4000 | 3650×1700×2000 |
| SQWD550 | 500/550 | 400/440 | 720 | WD269TAD48 | LTG-400 | 12 | 26.9 | 198 | 4200 | 3650×1700×2200 |
| SQWD600 | 550/600 | 440/480 | 792 | WD269TAD50 | LTG-440 | 12 | 26.9 | 198 | 4200 | 3650×1700×2200 |
| SQWD650 | 575/650 | 460/520 | 828 | WD269TAD56 | LTG-480 | 12 | 26.9 | 213.7 | 4500 | 3700×1700×2000 |
| SQWD715 | 650/715 | 520/570 | 936 | WD287TAD58 | LTG-550 | 12 | 26.9 | 221 | 4400 | 3700×1700×2200 |
| SQWD735 | 668/735 | 535/588 | 963 | WD287TAD61L | LTG-550 | 12 | 28.7 | 221 | 4400 | 3700×1700×2200 |
| SQWD770 | 700/770 | 560/618 | 1008 | WD287TAD61L | LTG-600 | 12 | 28.7 | 218 | 4500 | 3800×1700×2200 |
| SQWD850 | 775/850 | 620/680 | 1116 | WX287TAD68 | LTG-640 | 12 | 30.5 | 197 | 4600 | 4800×1800×2200 |
| SQWD890 | 813/890 | 650/715 | 1170 | WD327TAD73 | LTG-728 | 12 | 32.7 | 197 | 4500 | 4200×1700×2000 |
| SQWD960 | 875/960 | 700/770 | 1260 | WD327TAD78 | LTG-728 | 12 | 32.7 | 197 | 4500 | 4200×1700×2000 |
| SQWD1030 | 938/1030 | 750/825 | 1350 | WD327TAD82 | LTG-800 | 12 | 32.7 | 197 | 4600 | 4500×1800×2100 |
| SQWD1100 | 1000/1100 | 800/880 | 1440 | WD327TAD88 | LTG-800 | 12 | 32.7 | 197 | 4800 | 4520×1800×2100 |
| SQWD1170 | 1063/1170 | 850/930 | 1530 | WD327TAD92 | LTG-904 | 12 | 32.7 | 197 | 4800 | 4550×1800×2100 |
| SQWD1265 | 1150/1265 | 920/1012 | 1656 | WD327TAD100 | LTG-10 | 12 | 32.7 | 197 | 5200 | 4600×1800×2100 |
| SQWD1375 | 1250/1375 | 1000/1100 | 1800 | WD360TAD110 | LTG-10 | 12 | 35.9 | 197 | 7800 | 4800×2000×2350 |
| SQWD1500 | 1375/1500 | 1100/1200 | 1980 | WD360TAD120 | LTG-11 | 12 | 35.9 | 197 | 9000 | 4800×2300×2600 |
★Remarks:
1. Above Sanqpower Gensets are based on 50HZ,1500 RPM, 400/230V, PF0.8 3phase 4wires other special voltage can be satisfied.
2. Requirements for Soundproof Canopy, ATS, Synchronizing Parallel Control panels etc are optional.
3. We observe the rights of data’s adjustment without prior notification.
