Engine features:

• 6~16 serialized cylinders, universal primary components and reduced parts to simplify parts supply;

• Equipped with a variety of auxiliary apparatus and components for various purposes;

• Efficient turbocharger;

• Driven by air motor or electric motor. Some models may be started directly with compressed air.

• Able to be run under relatively humid conditions or at high

50Hz
Genset Model	Standby Power	Prime  Power	Engine Model	Alternator Model	Fuel Consumption	Genset Weight (Kg)		Genset overall LxWxH (MM)		Click for Detail Data
	kVa/kW	kVa/kW	Mitsubishi	Stamford	L/H	Open type	Silent  type	Open Type	Silent type
SQM750	750/600	650/520	S6R2--PTA-C	HCI544F	139	4750	6500	3750x1410x2200	5030x1860x2550
SQM825	825/660	750/600	S6R2-PTAA-C	LVI634B	170	5600	12200	3950x1600x2000	6050x2438x2896
SQM1375	1375/1100	1250/1000	S12R-PTA-C	LVI634G	266	9320	16850	4570x2100x2460	6058x2438x2896
SQM1500	1500/1200	1375/1100	S12R-PTA2-C	PI734B	281	10500	18300	4650x2100x2630	12192x2438x2896
SQM1650	1650/1320	1500/1200	S12R-PTAA2-C	PI734C	308	12317	18500	4920x2192x2810	12192x2438x2896
SQM1815	1813/1450	1650/1320	S16R-PTA-C	PI734D	310	14150	19200	5470x2200x2810	12192x2438x2896
SQM2000	2000/1600	1875/1500	S16R-PTA2-C	PI734E	418	14545	21780	5450x2600x3100	12192x2438x2896
SQM2250	2250/1800	2000/1600	S16R-PTAA2-C	PI734F	432	14900	21875	5850x2450x3430	12192x2438x2896

★Remarks:
1. Above Sanqpower Gensets are based on 50HZ,1500 RPM, 400/230V, PF0.8 3phase 4wires  other special voltage can be satisfied.
2. Requirements for Soundproof Canopy, ATS, Synchronizing Parallel Control panels etc are optional.
3. We observe the rights of data’s adjustment without prior notification.
